Customizable High Density Radio Shuttle Storage Pallet Racking for 2000-12000mm Height

Place of Origin : Jiangsu China

Model Number : HCS

Packaging Details : Plywood+Streach Film+Carton Board+Packing Belt

Supply Ability : 2000000 Kilogram/Kilograms per Month

MOQ : 1000 kilograms

Price : $0.90 - $1.50/kilograms

Type : Automated Retrieval

Material : Steel

Feature : Corrosion Protection

Use : Warehouse Rack

Depth : 8000-50000mm

Weight Capacity : 300-1500kgs/pallet

Width : 1000-1500mm

Height : 2000-12000mm

Color : Blue/Orange/Yellow/Grey etc.

Access Mode : FIFO & FILO

Quality : Industrial

Port : Nanjing,Shanghai

Contact Now

Radio shuttle pallet rack is one of the high density storage racks.Its storage ability is better than drive in pallet rack and share similar cost per pallet position with push back pallet rack.

The rack is suitable for the storage of goods with small varieties and large quantity. The rack takes both "first-in-last-out" and “first-in-first-out” access mode.

The rack could be used in logistics center, distribution center, food industry, chemical industry, furniture and wood industry,electronic industry, cold storage, etc. Its space utilization ratio is up to 80%.

Radio shuttle cart runs along the support rail. When store goods, remote controller gives order, radio shuttle follow order and carry pallet to its position automatically. Radio shuttle cart could count pallet quantity on the rail and show it on its screen.

Rack Parameter

Rack Type			radio shuttle pallet rack
Rack Cost			Low, Medium Low,Medium,√Medium high,High,Higher
Access Style			first in first out (FIFO); first in last out(FILO)
Structure			knock down or assembled,welded structure available
Forklift Asile			around 3200mm,depends on customer's forklift parameter
Load Capacity & Dimension	Load capacity		≤1500kgs/pallet
	length		950mm～1700mm
	depth/width		≤50000mm
	height		≤12000mm
	level		≥2
Components	core components		frame(upright,also called column or post,bracing,base plate,fasteners),beam, spacer support rail, radio shuttle cart
	highly recommended components		upright protector,frame protector,etc.
Core Components Specification (mm)	upright section	face	80,90,100,120
		height	60,67,70,95,135
		thickness	1.5,1.8,2.0,2.3,2.5,3.0
		adjust step	75mm
	beam section	height	50,60
		width	40,50
		thickness	1.5,2.0
	support rail section	thickness	2.3,2.5,2.75
Material			Q235(ss400),Q355(S355B,S355JR)
Finish			Epoxy resin electrostatic spraying(powder coating),galvanized
Coating thickness			no less than 60um for average thickness for
Color			ral5015(sky blue),ral5005(signal blue),ral2004(pure orange),ral1003(signal yellow),ral7035(light grey) Customized colors are available when order above 2*40gp containers

Customizable High Density Radio Shuttle Storage Pallet Racking for 2000-12000mm Height

FAQ

Question 1: Are you factory or trading company?
Answer 1: We are factory and also do trading products related to warehouse rack.

Question 2:Do you provide sample? Is it free or extra?
Answer 2: We provide sample parts free charged and you just need to pay the freight. When need whole sample rack for testing the
possibility, please contact us for sample cost.

Question 3: I’d like to visit you. Which city should I go?
Answer 3: We are in Nanjing. When needed, we can help you book hotel, traffic ticket. And we will pick you up to the destination
place. We have sales person and driver who will be with you during the visit. You don’t have to worry about the traffic matter.

Question 4: Why choose you?
Answer 4:
1. HBrack have engineers who are professional in design warehouse rack more than 10 years and could handle from simple structure
to complex one.
2. Your money is safe with HBrack. We accept trading through 3rd party. The sales person have rich experience in warehouse rack,
all the personal information is trackable.
3. HBrack offer different design to help client control budget.
